זחלן פורד - TRX4 FORD F150 Hi Trail
מק"ט / דגם: 92046-4
יצרן: TRAXXAS
| Model Name: |
TRX-4 Ford F-150 High Trail Edition |
| Model Type: |
Trail / Crawler |
| Model Skill Level: |
1 |
| Chassis: |
Extended steel ladder frame |
| Scale: |
1/10 |
| Weight: |
7.34 lb (3.33 kg) |
| Length: |
22.30 inches (566 mm) |
| Width: |
10.60 inches (270 mm) |
| Front Track: |
10.60 inches (270 mm) |
| Rear Track: |
10.60 inches (270 mm) |
| Height: |
10.82 inches (275 mm) |
| Wheelbase: |
13.23 inches (336 mm) |
| Center Ground Clearance: |
4 inches (99 mm) |
| Drivetrain: |
Shaft-driven 4WD |
| Transmission: |
2-speed high/low, remote shifting |
| Differential Type: |
4 gear, remote locking |
| Gear Pitch: |
32 pitch |
| Servo(s): |
2075X metal gear, digital high-torque waterproof |
| Radio System: |
TQi™ 2.4 GHz 4-channel transmitter with 6533 receiver |
| Battery Compartment Specs: |
159 mm X 47 mm X 23 mm, 26 mm |
MOTOR SPECS
| Motor Name: |
Titan® 550 21T reverse rotation |
| Motor Type: |
High-torque brushed motor |
| Motor Weight: |
390g (13.76 oz) |
| Motor Length: |
3.071″ (78 mm) overall length, 2.25″ (57 mm) can length |
| Motor Diameter: |
1.532″ (39 mm diameter) |
| Motor Shaft Size: |
3 mm |
| Motor Connector Type: |
Bullet |
